Cervical Spine

Cervical Spine

Musculoskeletal
All Phantoms

Cervical spine phantom with vertebral bodies C1-C7, intervertebral discs, spinal cord, nerve roots, and vertebral arteries

Modalities: CT MRI DIGITAL RADIOGRAPHY
Images: 5
Structures: 9
Compatible Instruments: 11
Open in Simulator

Image Library

Filter:
C-Spine MRI — Sagittal
C-Spine MRI — Sagittal

Sagittal MRI of the cervical spine showing spinal cord

MRI Downloaded 2026-03-16
T2 Sagittal

https://commons.wikimedia.org/wiki/File:Cervical%20Spine%20MRI%20showing%20degenerative%20changes%20closeup.jpg

C-Spine CT — Sagittal
C-Spine CT — Sagittal

CT of the cervical spine

CT Downloaded 2026-03-16
Sagittal Bone

https://commons.wikimedia.org/wiki/File:CT%203D%20reconstruction%20image%20of%20cervical%20spine%20Posterior%20view.png

C-Spine X-ray — Lateral
C-Spine X-ray — Lateral

Lateral radiograph of the cervical spine

DIGITAL RADIOGRAPHY Downloaded 2026-03-16

https://commons.wikimedia.org/wiki/File:X-ray%20of%20the%20cervical%20spine%20of%20a%2020%20year%20old%20male%20-%20lateral.jpg

C-Spine MRI — Sagittal
C-Spine MRI — Sagittal

Sagittal MRI of the cervical spine showing spinal cord

MRI Downloaded 2026-03-16
T2 Sagittal

https://commons.wikimedia.org/wiki/File:Cervical%20Spine%20MRI%20showing%20degenerative%20changes.jpg

C-Spine CT — Sagittal
C-Spine CT — Sagittal

CT of the cervical spine

CT Downloaded 2026-03-16
Sagittal Bone

https://commons.wikimedia.org/wiki/File:Cervical%20spine%20Anterior.png

Tissue Structures

Structure Density (HU) T1 (ms) T2 (ms) Echo Rel. Size
Vertebral Body 250 400 45 0.85 18%
Cortical Bone 1200 300 1 0.95 8%
Disc 60 1200 80 0.3 5%
Spinal Cord 30 900 70 0.0 4%
Csf 5 4000 2000 0.0 4%
Vertebral Artery 45 1200 50 0.2 2%
Nerve Root 35 1000 75 0.0 2%
Muscle 40 900 35 0.4 14%
Fat -100 250 80 0.6 10%

Compatible Imaging Instruments

Model Manufacturer Modality
Aquilion ONE PRISM Canon Medical Systems CT
Vantage Galan 3T Canon Medical Systems MRI
SCENARIA View Fujifilm Healthcare CT
Revolution Apex GE HealthCare CT
SIGNA Hero GE HealthCare MRI
SIGNA Premier GE HealthCare MRI
Spectral CT 7500 Philips Healthcare CT
Ingenia Ambition 1.5T Philips Healthcare MRI
SOMATOM Force Siemens Healthineers CT
MAGNETOM Vida Siemens Healthineers MRI
MAGNETOM Terra.X Siemens Healthineers MRI
